YL-608 Perforating Machine

Application: This machine is suitable for perforating PE Protective film,non-woven fabric,adhesive film etc.

Features:

1. PLC programming, touch screen  and manual interface centralized control.
2. Adopt automatic length counter, servo-motor control the precision and auto tension, rewunding material neatly.
3. Machine with air expansion unwinding shaft, easlily for loading  the materil roll a nd highly improves the working efficiency

  • Product Detail
  • Inquiry

Technical data:

Width  1300mm
 Unwind O.D  800MM
 Rewind O.D  300MM
 Inner Size of Paper core  32-76.2MM
 Voltage  220V/380V/415V
 Power  6KW
 Speed  0-80M/MIN
